COMPAS KB Release : July 2025

• 3VA

• 3WA Breaker

• Busway Systems

• Load Center

• LVS/RCS

• MCC

• Panelboard

• Power Mod

• Russelectric Products

• SieBreak

• Switchboard

• Transformer

• Added 1200A Breaker Enclosure

• Added Large Frame Motor Operator

• Added Custom Door Mounted Operator

Technical Info

• KB Version: 00.00.12.01

• Price Version: 20250501

• Release Date: 7/2025

• EMS B25 Option plug correction to include 3000A selection

Technical Info

• KB Version: 01.01.01.12

• Price Version: NA

• Release Date: 7/2025

Bus Plug:

• Update to technical attribute layout in Bus Plug drawings

Busway:

• Update to technical attribute layout in Feeder, Riser, and Plug-in drawings

Technical Info

• KB Version: 00.00.54.01

• Price Version: 20250501

• Release Date: 7/2025

Add or remove misc. Catalogs per Product Management.

Deleted:

• B3100S, WB3100

Added:

• W0204L1060G25, W0204L1060G30, E0816ML1125FGP, E0816ML1125SGP, SN2020L1125P4, SN3048L1200P4, SN4040L1200P4, SNW4264B1200, W0408ML1125G, W0816ML1125G

• Added new Load Center Type values to simplify selection:

• Load Ctr w/35kA Surge, Small Circuit LC 8-24 Cir Max w/GB, Renovation Panel w/GB

Technical Info

• KB Version: 01.01.04.01

• Price Version: 20250101

• Release Date: 07/2025

3WA Extended Ground Fault

• 3WA Breaker KB updated to allow Extended Ground Fault as selectable option on ETU600 LSIG trip units.

• Will generate correct breaker catalog number.

Remote Breaker Operator (RBO) and Electrically Operated (EO) Rule

• Remote Breaker Operator requires EO Breaker

• Global EO selection defaults to Yes if RBO selected in Automation tab.

• Conflict Rule at breaker level if RBO Receptacle is True without EO Breaker.

3WA Single Cradle Lock Provision not available (R62 Z-option)

• Restricted KIRK Lock Provision (which generated R62) as a selectable option until 3WA Breaker KB is updated.

• Use Double KIRK Lock Provision in the interim.

Bug Fixes

• Incorrect Functional Cost for SPD Surge Counter corrected.

• Mfg KB - Incorrect Breaker Door for Cradle Locks (4 Pole and 3WA) corrected.

• Mfg KB – Vent Stack not generating when Custom Section now generating.

• Mfg KB – Wrong Sealing Ring material for 3WA corrected.

Technical Info

• KB Version: 00.00.61.01

• Price Version: 20121101

• Release Date: 07/2025

• Added 3VA CB for heavy duty (Innova) contactor size 1-4 and changed CB default to 3VA.

• Updated Sentron CB starter short circuit ratings. CED CB required instead of ED CB for SIRIUS above 480V 30K, 600V 18K and for heavy duty (Innova) above 480V 65K, 600V 18K .

• Added new standard WD wiring diagrams for 3VA circuit breaker heavy duty (Innova) contactor with ESP200 overload FVNR, FVR, 2S1W, 2S2W and 3VA circuit breaker SIRIUS contactor with SIMOCODE pro V overload FVNR, FVR. Removed old standard D6 wiring diagrams Sentron circuit breaker and fusible heavy duty (Innova) contactor with ESP200 overload FVNR, FVR, 2S1W, 2S2W, RVAT, YDO, YDC, PW.

• Changed SIRIUS size 4 standard wiring diagrams so that they are generated when surge suppressor is none as the SIRIUS size 4 has an internal MOV. Changed size 5, 6 FVR standard wiring diagrams to include heavy duty (Innova).

• Added note When selected; SIS power wire will be provided at all locations possible. However there are certain stab assemblies where the required wire gauges are not available as SIS wire. In these locations MTW power wire will be provided.

• Replaced pull apart power terminal blocks PLU1, PSU1 with stationary power terminal blocks. Power terminal blocks screw pull-apart, lock pull-apart are no longer available and pull-apart is now only used for size 1.

• Added AE technical review flag for NEMA 3R with top incoming.

• 480V 100K starters 7.5HP, 15HP, 25-60HP are now defaulting frame amperage.

• Changed MCC type description on drawing specification from TIASTAR to TIASTAR NON ARC RESISTANT, from ARC RESISTANT 0.05 SEC to TIASTAR ARC RESISTANT .05S, from ARC RESISTANT 0.15 SEC to TIASTAR ARC RESISTANT .15S.

• 3 phase 4 wire no longer has red conflict with 3VA breakers with trip unit types ETU556, ETU560, ETU830, ETU856, ETU860.

• Now after copying an MCC unit to a unit only the MCC level characteristics that are conflicted and need to be changed will show as red instead of showing characteristics as red that don’t need to be changed.

• When copying an MCC unit to a unit only the height characteristic no longer loses its value.

• Wiring Class II (Std. Unit/Inter-wiring Diagram), IIs(Cust Unit/Inter-wiring Diagram) and Wiring Type C (Top Master ctrl/power tb), C (Bottom Master ctrl/power tb) are no longer allowed for unit only.

• Changed MCP Range from 750-900 to 750-1500 for 3VA52 250A frame 250A trip. Changed MCP Range from 750-1500 to 1200-2400 for 3VA54 600A frame 400A trip. Changed MCP Range from 3000-6000 to 4000-6000 for 3VA54 600A frame 500A trip. Changed MCP Range from 3000-6000 to 4200-6000 for 3VA54 600A frame 600A trip.

• Changed order of voltage indicator common factory options so that non bezel options appear before bezel options.

Technical Info

• KB Version: 00.00.66.01

• Price Version: 20240701

• Release Date: 7/2025

• Resolved issue with 3VA62 Main lug incorrect description

• Added restriction for 30”W Type 1 enclosures when Endwall with knockouts is selected

• Plugin Panel fixes: resolved issue with width not getting displayed in layout

• Removed additional lead time for HBQDPF-GFCI & HBQDQE-GFCI in P2 & P3 panels and reduced it in P1 panels

Technical Info

• KB Version: 01.01.111.01

• Price Version: 20250101

• Release Date: 07/2025

COMPAS PowerMod Maintenance items:

• Lug Landing Pad LLPV600 – issue resolved.

• The old Sentron LLP600 was being shown.  This is now corrected and LLPV600 is being added as a child line as expected.

Technical Info

• KB Version: 00.00.39.01

• Price Version: 20250501

• Release Date: 07/2025

Russelectric ATS Mods

Existing ‘RPTCS Upgrade’ has been renamed to ‘ATS Control Retrofit’

• All open orders will be processed same way – complete retrofit

New ‘RPTCS – Upgrade’ option has been added

• This option offers controller upgrade for existing ATS

• Replace model 2000, 2000+ and some relay versions

• Significantly reduced downtime for change out

• Provides superior performance & enhanced information

• Cost effective solution than replacing entire switch

Russelectric LV Switchgear

Spare Parts will be at the bottom of the configuration

• Previously, spare parts lines were added in sequence, which caused occasional line cancellations during ECR/ICR processes. Going forward, for any new orders, spare parts lines should be placed at the bottom of the list, just above the ship-loose items.

Technical Info

ATS Mods

• KB Version: 00.00.36.01

• Release Date: 07/2025

SWGR

• KB Version: 00.00.31.01

• Release Date: 07/2025

• Russelectric ATS Mods

• Added Cable Pull LV Compartment for 36” front access configurations.

• Added Center-fed for load side Auxiliary cable pull.

• List price updated for IR Viewports.

Drawing Updates

• Added overall width dimension for all drawings.

• New graphics for cable pull LV Compartment.

• Updated section height for NEMA 3R from 105.20” to 105.

Technical Info

• KB Version = 00.00.17.01

• Price Version = 20251605

• Release Date: 07 / 2025

3VA:

• Add additional 3VA US and Canadian series rating combinations

Switchboard:

• Update Heater / CPT selection logic

• Update logic for EUSERC N3R conflict messaging on existing configurations

• Update FS1 3WA depth rules (previously setting 38D for FS1 with standard GF)

• Add Load IR window selection and pricing for utility metering with load connections

Technical Info

• KB Version: 01.01.86.01

• Price Version: 20250501

• Release Date: 7/28/2025

Misc. Catalogs Phased-out and removed from Configuration.

• There were many catalogs for all series that were seldom ordered or never ordered.

• PM determined that we should remove from SAP before adding matching numbers for the 3rd supplier that is pending.

• These numbers were identified and removed from KB tables and set to PM490 in SAP.

• Additional 3F5Y catalogs were added to SAP as saleable for Series H and J.

• These were added to KB tables to allow for type matching.

• Series J 3F5T500… series were removed from KB and phased out per PM.

Technical Info

• KB Version: 00.00.08.01

• Price Version: 20250501

• Release Date: 07/2025
